Independent research and development capability
The production department is responsible for overseeing the entire company's production work, maintaining safe, civilized, and balanced production. When there are conflicts between production progress, cost, quantity, and quality, the "quality first" policy is implemented.
For many years, the production department has adhered to the policy of "quality first", ensuring high product quality, stability, consistency, and reliability. At present, the production process technology, production equipment and site, testing system, and supply chain system can meet the demand for 3K/month shipment scale and ensure product quality, with stable production capacity and product delivery capability
R&D Team
Led by experts who enjoy the lifelong expert allowance of the State Council, Harbin Institute of Technology Electrical Research Institute and other universities cooperate with industry, academia and research, and the proportion of technical personnel in the R&D team65%.
Patent Layout
The proportion of patent applications in the field of RF relays in China exceeds 60%, including 10+invention patents, ensuring independent controllability.
Multidisciplinary Joint Modeling and Simulation
There are over 200 RF transmission models, over 100 electromagnetic construction models, and over 100 material mechanics models.
Modular design is our technological advantage
High reliability, significantly shortened design cycle, and accelerated product upgrade iteration.
Implement the Xike Enterprise Standard, GJB 9375-2018, GJB9001C Quality Management System
Ensure high quality, stability, consistency, and reliability of the product.
- patent technology
As of 2023, Xike has applied for 65 patents and granted 48. Among them, there are 12 invention patent applications, 2 of which have been authorized, and 10 of which are under substantive examination; 2 design patent applications and 2 authorizations; 51 utility model patent applications were filed and 44 were authorized.
Multi channel shared ladder compensation
Resolve the issue of significant increase in insertion loss after channel expansion.
Micro eddy current permanent magnet structure
Improved magnetic retention and reduced the volume and weight of aerospace grade products by more than 10%.
Double layer spring positioning
To achieve frictionless reciprocating motion and ensure reliable operation of the product for 10 million times..
Dual medium support technology
Reduce the waveform transmission loss of the product.
Integrated structural technology
Solved the problem of cumulative error, reduced the volume, improved the product's resistance to impact and vibration, and ensured the stability requirements of the product when the rocket accelerates away from gravity.
- Simulation technology
The Xike R&D team has jointly modeled more than 400 items in the three major fields of RF, electromagnetic, and mechanics for RF relays/RF switches, improving product design reliability and shortening product development cycles..
Joint modeling and simulation in three major fields
- RF modeling and simulation
- Electromagnetic modeling and simulation
- Mechanical modeling and simulation
- Modular design
- Transmission module
Design:Adopting a double spring structure, piano key design, and frictionless symmetrical design.
advantage:1. High stability - contact stability, pressure stability, and resistance stability. 2. High reliability - frictionless design with push rod, high lifespan.
- RF Module
Design:Accurate matching of inner and outer conductor dimensions, stable and reliable structure.
advantage:The RF cavity is compatible with SMA and 2.92 interfaces, and can be flexibly interchanged.
- Electromagnetics Module
Design:Permanent magnet steel, circular layout, fully utilizing magnetic efficiency.
advantage:Permanent magnets have high stability, low power consumption, and small size.
- Control circuit module
